Residential Vertical Platform Lifts
We have two different residential vertical platform lifts to choose from; the Atlas and the Hercules. If you have questions about which vertical platform lift is right for you, please call us today and let us guide you through the process.
$3,410.59
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:30"
- Maximum Lift Height:30"
- Lift Speed (FPM):9
- Arrives Assembled:No
- Drive System:Direct Drive ACME Screw
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Alarm Button:Included
- Platform Type:Non-skid (Epoxy crushed and recycled tires)
- Platform Size:36"W x 54"L
- Optional Platform Sizes:n/a
- Platform Configuration:Straight-Thru Access
- Optional Platform Configurations:n/a
- Guard Panel:Not Included
- Maximum Stops:2
$3,970.59
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:53"
- Maximum Lift Height:53"
- Lift Speed (FPM):10.4
- Portable:No
- Arrives Assembled:Yes
- Drive System:Acme Screw Drive
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Platform Size:36" x 48" (34" Usable Width)
- Optional Platform Sizes:36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
- Platform Configuration:Straight-Thru Access
- Guard Panel:36" for 36"x48" Platform, all others 42"
$4,111.77
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:53"
- Maximum Lift Height:53"
- Lift Speed (FPM):10.4
- Portable:No
- Arrives Assembled:Yes
- Drive System:Acme Screw Drive
- Battery Powered Option:No
- Constant Pressure Platform Control:Yes
- Platform Size:36" x 48" (34" Usable Width)
- Optional Platform Sizes:36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
- Platform Configuration:Straight-Thru Access
- Guard Panel:36" for 36"x48" Platform, all others 42"
$4,188.24
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:53"
- Maximum Lift Height:171"
- Lift Speed (FPM):10.4
- Portable:No
- Arrives Assembled:Yes
- Drive System:1" Diameter Acme Screw Drive
- Optional Drive Systems:None Availaboe
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Emergency Stop Platform Control:Included
- Alarm Button:Optional
- Keyed Platform Control:Optional
- Call-Send Controls:One Per Stop Included
- Optional Call-Send Controls:Keyed and/or Wireless
- Platform Type:Solid with Non-Skid Coating
- Platform Size:36" x 48" (34" Usable Width)
- Optional Platform Sizes:36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
- Platform Configuration:Straight-Thru Access
- Optional Platform Configurations:Same Side Entry-Exit, 90 Degree Adjacent Access
- Upper Landing Gate:Optional
- Upper Access Ramp:None Available
- Lower Access Ramp:36" Fixed or Auto-Folding Standard, Optional 42" Fixed or Auto-Folding
- Grab Rail:Included
- Guard Panel:36", Optional 42"
- Maximum Stops:3
- Other Options:Fire-Rated Doors, Automatic Door Openers
$4,229.42
+ Plus Shipping
- Lifting Capacity:800 lb
- Standard Lift Height:64"
- Maximum Lift Height:64"
- Lift Speed (FPM):12
- Portable:No
- Arrives Assembled:Yes
- Drive System:Acme Screw
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Emergency Stop Platform Control:Included
- Alarm Button:Included
- Keyed Platform Control:Included
- Platform Type:Non-skid (Epoxy crushed and recycled tires)
- Platform Size:36" x 54"
- Platform Configuration:Straight-Thru Access
- Maximum Stops:2
$4,229.42
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:64"
- Maximum Lift Height:160"
- Lift Speed (FPM):9
- Portable:Optional
- Arrives Assembled:No
- Drive System:Direct Drive ACME Screw
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Alarm Button:Included
- Platform Type:Non-skid (Epoxy crushed and recycled tires)
- Platform Size:W 34"-36" x L 54"-60"
- Optional Platform Sizes:Custom: W (31" to 42") x L (46" to 66")
- Platform Configuration:Straight-Thru Access
- Optional Platform Configurations:Same Side Entry-Exit, 90 Degree Adjacent Access
- Grab Rail:Optional
- Maximum Stops:3
$4,347.06
+ Plus Shipping
- Lifting Capacity:600 lb
- Standard Lift Height:30"
- Maximum Lift Height:60"
- Lift Speed (FPM):8
- Arrives Assembled:Yes
- Drive System:Rack and Pinion
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Emergency Stop Platform Control:Included
- Call-Send Controls:Wired
- Optional Call-Send Controls:Wireless or Keyed Wired
- Platform Size:34"x54"
- Upper Landing Gate:Optional
- Maximum Stops:2
$6,703.42
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:53"
- Maximum Lift Height:171"
- Lift Speed (FPM):10
- Portable:None Available
- Arrives Assembled:Yes
- Drive System:1" Diameter Acme Screw Drive
- Optional Drive Systems:None Available
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Emergency Stop Platform Control:Included
- Alarm Button:Optional
- Keyed Platform Control:Optional
- Call-Send Controls:One Per Stop Included
- Optional Call-Send Controls:Keyed and/or Wireless
- Platform Type:Solid with Non-Skid Coating
- Platform Size:36" x 48" (34" Usable Width)
- Optional Platform Sizes:36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
- Platform Configuration:Straight-Thru Access
- Optional Platform Configurations:Same Side Entry-Exit, 90 Degree Adjacent Access
- Upper Landing Gate:Optional
- Upper Access Ramp:None Available
- Lower Access Ramp:36" Fixed or Auto-Folding Standard, Optional 42" Fixed or Auto-Folding
- Grab Rail:Included
- Guard Panel:36", Optional 42"
- Maximum Stops:3
- Other Options:Fire-Rated Doors, Automatic Door Openers
$7,052.95
- Lifting Capacity:750 lb
- Standard Lift Height:48"
- Maximum Lift Height:168"
- Lift Speed (FPM):15
- Portable:No
- Arrives Assembled:Yes
- Drive System:Dual Winding Cable Drums with 3/8" Cables
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Emergency Stop Platform Control:Yes
- Alarm Button:Yes
- Call-Send Controls:RF Call/Send Station (1 per landing provided)
- Optional Call-Send Controls:Yes
- Platform Type:Non-Skid
- Platform Size:36" x 48"
- Optional Platform Sizes:36"x54", 36"x60", 42"x54", 42"x60", Custom
- Platform Configuration:Single Entry/Exit
- Optional Platform Configurations:Pass Through, 90 Degree
- Guard Panel:42"
- Maximum Stops:3
- Other Options:Enclosure, Solar Battery Charger, Bluetooth Controller
$9,410.59
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:64"
- Maximum Lift Height:64"
- Lift Speed (FPM):9
- Portable:Yes
- Arrives Assembled:No
- Drive System:Direct Drive ACME Screw
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Alarm Button:Included
- Platform Type:Non-skid (Epoxy crushed and recycled tires)
- Platform Size:W 34"-36" x L 54"-60"
- Optional Platform Sizes:Custom: W (31" to 42") x L (46" to 66")
- Platform Configuration:Straight-Thru Access
- Grab Rail:Optional
- Maximum Stops:2
$11,570.59
+ Plus Shipping
- Lifting Capacity:750 lb
- Standard Lift Height:53"
- Maximum Lift Height:171"
- Lift Speed (FPM):10
- Arrives Assembled:No
- Drive System:1" diameter ACME Scrwe
- Battery Powered Option:Yes
- Constant Pressure Platform Control:Yes
- Emergency Stop Platform Control:Pit Switch Standard, Safety Underpan Option
- Alarm Button:Lighted Emergency Stop with Alarm Option
- Keyed Platform Control:Optional
- Call-Send Controls:One per Stop Included
- Optional Call-Send Controls:Keyed and/or Wireless
- Platform Type:Solid with Non-Skid Coating
- Platform Size:36" x 60" x 42" (34" Usable)
- Optional Platform Sizes:42"x 60" (40" Usable)
- Platform Configuration:Straight Thru Access
- Optional Platform Configurations:Same Side Entry-Exit, 90 Degree Adjacent Access
- Upper Access Ramp:None Available
- Lower Access Ramp:36" or 42" Fixed Ramp
- Grab Rail:Optional
- Guard Panel:42"
- Maximum Stops:3
- Other Options:Fire-Rated Doors, Automatic Door Openers
